Return Air Grilles & Filter Grilles

G35

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec eget auctor velit, et suscipit erat. Donec dapibus purus id eros auctor, a scelerisque urna ornare. Pellentesque vel bibendum arcu, a hendrerit purus. Etiam vel arcu quis nibh blandit faucibus. Morbi id purus diam. Vestibulum eu congue nisi, id dictum ex.

  • Lanced face
  • 1/3” spaced fins
  • Steel construction (G35)
  • Vast number of sizes
  • White finish
  • Made in the U.S.A.
Catalog
Series G35 SubmittalSeries A35 Submittal
Part #DescriptionCtn QtyList Price Each
G35W 06046" x 4" White20--
G35W 06066" x 6" White20--
G35W 06106" x 10" White20--
G35W 06126" x 12" White20--
G35W 06146" x 14" White20--
G35W 06166" x 16" White12--
G35W 06206" x 20" White12--
G35W 06246" x 24" White12--
G35W 06306" x 30" White12--
G35W 08048" x 4" White20--
G35W 08068" x 6" White20--
G35W 08088" x 8" White20--
G35W 08108" x 10" White20--
G35W 08128" x 12" White20--
G35W 08148" x 14" White20--
G35W 08168" x 16" White12--
G35W 08188" x 18" White12--
G35W 08208" x 20" White12--
G35W 08248" x 24" White12--
G35W 08308" x 30" White12--
G35W 100310" x 3" White20--
G35B 100310" x 3" Brown20--
G35W 100410" x 4" White20--
G35B 100410" x 4" Brown20--
G35W 100610" x 6" White20--
G35W 100810" x 8" White20--
G35W 101010" x 10" White12--
G35W 101210" x 12" White12--
G35W 102010" x 20" White12--
G35W 102410" x 24" White12--
G35W 103010" x 30" White12--
G35W 103610" x 36" White5--
G35W 120312" x 3" White20--
G35B 120312" x 3" Brown20--
G35W 120412" x 4" White20--
G35W 120612" x 6" White20--
G35W 120812" x 8" White20--
G35B 120812" x 8" Brown20--
G35W 121012" x 10" White12--
G35W 121212" x 12" White12--
G35B 121212" x 12" Brown12--
G35W 121812" x 18" White12--
G35W 122012" x 20" White12--
G35W 122412" x 24" White12--
G35W 123012" x 30" White12--
G35W 140314" x 3" White20--
G35W 140414" x 4" White20--
G35W 140614" x 6" White20--
G35B 140614" x 6" Brown20--
G35W 140814" x 8" White20--
G35B 140814" x 8" Brown20--
G35W 141014" x 10" White12--
G35W 141214" x 12" White12--
G35W 141414" x 14" White12--
G35B 141414" x 14" Brown12--
G35W 141614" x 16" White12--
G35W 141814" x 18" White12--
G35W 142014" x 20" White12--
G35W 142414" x 24" White12--
G35W 142514" x 25" White12--
G35W 143014" x 30" White12--
G35W 160616" x 6" White12--
G35B 160616" x 6" Brown12--
G35W 160816" x 8" White12--
G35W 161016" x 10" White12--
G35W 161216" x 12" White12--
G35W 161416" x 14" White12--
G35W 161616" x 16" White12--
G35W 162016" x 20" White12--
G35W 162416" x 24" White12--
G35B 162516" x 25" Brown12--
G35W 180618" x 6" White12--
G35W 180818" x 8" White12--
G35B 180818" x 8" Brown12--
G35W 181018" x 10" White12--
G35W 181218" x 12" White12--
G35W 181618" x 16" White12--
G35W 181818" x 18" White12--
G35W 182418" x 24" White12--
G35W 183018" x 30" White12--
G35W 200620" x 6" White12--
G35B 200620" x 6" Brown12--
G35W 200820" x 8" White12--
G35B 200820" x 8" Brown12--
G35W 201020" x 10" White12--
G35B 201020" x 10" Brown12--
G35W 201220" x 12" White12--
G35W 201420" x 14" White12--
G35W 201620" x 16" White12--
G35W 202020" x 20" White12--
G35W 202420" x 24" White12--
G35W 202520" x 25" White12--
G35B 202520" x 25" Brown12--
G35W 240424" x 4" White12--
G35B 240424" x 4" Brown12--
G35W 240624" x 6" White12--
G35W 240824" x 8" White12--
G35W 241024" x 10" White12--
G35W 241224" x 12" White12--
G35W 241424" x 14" White12--
G35W 241624" x 16" White12--
G35W 241824" x 18" White12--
G35W 242024" x 20" White12--
G35W 242424" x 24" White12--
G35B 242424" x 24" Brown12--
G35W 243024" x 30" White12--
G35W 250825" x 8" White12--
G35W 251625" x 16" White12--
G35W 252025" x 20" White12--
G35W 252525" x 25" White5--
G35W 300430" x 4" White12--
G35W 300630" x 6" White12--
G35W 300830" x 8" White12--
G35W 301030" x 10" White12--
G35W 301230" x 12" White12--
G35W 301430" x 14" White12--
G35W 301630" x 16" White12--
G35W 301830" x 18" White12--
G35W 302030" x 20" White12--
G35W 302430" x 24" White12--
G35W 360836" x 8" White5--
Unit SizeFace Velocity300400500600700
10x6Cfm91121152182212
Ak .303Pt.013.0230.037.052.072
10x8Cfm121162202243283
Ak .404Pt.012.022.035.050.068
10x10Cfm152202253303354
Ak .505Pt.012.021.034.048.066
12x6Cfm111148186223260
Ak .371Pt.013.022.035.051.070
12x8Cfm148198247297346
Ak .495Pt.012.022.034.049.066
12x10Cfm186247309371433
Ak .619Pt.012.021.033.047.064
12x12Cfm223297371445520
Ak .742Pt.011.020.032.045.062
14x6Cfm132176220263307
Ak .439Pt.012.022.035.050.068
14x8Cfm176234293351410
Ak .585Pt.012.021.033.047.065
14x10Cfm220293366439512
Ak .732Pt.011.020.032.045.062
14x12Cfm263351439527615
Ak .878Pt.011.020.031.045.060
14x14Cfm307410512615717
Ak 1.025Pt.011.019.030.043.059
16x8Cfm203270338406473
Ak .676Pt.012.021.033.046.063
16x10Cfm254338423507592
Ak .845Pt.011.020.031.045.061
16x16Cfm406541676811946
Ak 1.352Pt.010.018.029.042.057
18x6Cfm167223278334390
Ak .557Pt.012.021.034.048.065
18x8Cfm223297371445520
Ak .742Pt.011.020.032.045.062
18x10Cfm278371464557649
Ak .928Pt.011.020.031.044.060
18x18Cfm50166883510021169
Ak 1.670Pt.010.018.027.040.055
20x6Cfm182243303364424
Ak .606Pt.012.021.033.047.064
20x10Cfm303404505606707
Ak .808Pt.011.019.030.043.059
20x12Cfm364485606728849
Ak 1.213Pt.011.019.030.042.057
20x14Cfm424566707849990
Ak 1.415Pt.010.018.029.041.056
20x20Cfm606808101112131415
Ak 2.021Pt.010.017.028.039.053
24x6Cfm223297371445520
Ak .990Pt.011.020.032.045.062
24x10Cfm371495619742866
Ak 1.237Pt.011.019.030.042.057
24x12Cfm4455947428911039
Ak 1.485Pt.010.018.029.041.056
24x14Cfm52069386610391212
Ak 1.732Pt.010.018.028.040.055
24x24Cfm8911188148517812078
Ak 2.969Pt.009.016.026.037.050
30x6Cfm273364455546637
Ak .910Pt.011.020.031.044.060
30x8Cfm364485606728849
Ak 1.213Pt.011.019.030.042.057
30x10Cfm4556067589101061
Ak 1.516Pt010.018.029.041.055
30x12Cfm54672891010911273
Ak 1.819Pt.009.016.026.037.050
30x14Cfm637849106112731486
Ak 2.122Pt.010.017.027.039.052
30x18Cfm8191091136416371910
Ak 2.729Pt.009.017.026.038.050
30x20Cfm9101213151618192122
Ak 3.032Pt.009.016.026.037.050
30x24Cfm10911455181921832547
Ak 3.632Pt.009.016.025.036.048

Note:

Submittals sheets are available as interactive pdf forms which can be completed electronically. To access this functionality, you must download the sheets and open in a pdf reach such as the Adobe Reader.
By default, these submittals will open in a new browser window. Browsers do not support interactive pdf fields.
