Return Air Grilles & Filter Grilles

FG3

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec eget auctor velit, et suscipit erat. Donec dapibus purus id eros auctor, a scelerisque urna ornare. Pellentesque vel bibendum arcu, a hendrerit purus. Etiam vel arcu quis nibh blandit faucibus. Morbi id purus diam. Vestibulum eu congue nisi, id dictum ex.

  • Lanced, removable face
  • 1/3” spaced fins
  • Thumb latch for easy opening
  • Uses 1” filter (not included)
  • Steel construction (FG3)
  • Aluminum construction (AFG3)
  • White finish
  • Made in the U.S.A.
Catalog
Series FG3 SubmittalSeries AFG3 Submittal
Part #DescriptionCtn QtyList Price Each
FG3W 1010 10" x 10" White1--
FG3W 1020 10" x 20" White1--
FG3W 1212 12" x 12" White1--
FG3W 141014" x 10" White1--
FG3W 1414 14" x 14" White1--
FG3W 1420 14" x 20" White1--
FG3W 1424 14" x 24" White1--
FG3W 1425 14" x 25" White1--
FG3W 1430 14" x 30" White1--
FG3W 1616 16" x 16" White1--
FG3W 1620 16" x 20" White1--
FG3W 162416" x 24" White1--
FG3W 1625 16" x 25" White1--
FG3W 1812 18" x 12" White1--
FG3W 1818 18" x 18" White1--
FG3W 2010 20" x 10" White1--
FG3W 2012 20" x 12" White1--
FG3W 2014 20" x 14" White1--
FG3W 2016 20" x 16" White1--
FG3W 2018 20" x 18" White1--
FG3W 2020 20" x 20" White1--
FG3W 2024 20" x 24" White1--
FG3W 2025 20" x 25" White1--
FG3W 2030 20" x 30" White1--
FG3W 2412 24" x 12" White1--
FG3W 2414 24" x 14" White1--
FG3W 2418 24" x 18" White1--
FG3W 2424 24" x 24" White1--
FG3W 2430 24" x 30" White1--
FG3W 2514 25" x 14" White1--
FG3W 2516 25" x 16" White1--
FG3W 251825" x 18" White1--
FG3W 2520 25" x 20" White1--
FG3W 252525" x 25" White1--
FG3W 3008 30" x 8" White1--
FG3W 3010 30" x 10" White1--
FG3W 3012 30" x 12" White1--
FG3W 3014 30" x 14" White1--
FG3W 3018 30" x 18" White1--
FG3W 3020 30" x 20" White1--
FG3W 302430" x 24" White1--
FG3W 3030 30" x 30" White1--
FG3W 3616 36" x 16" White1--
Unit SizeFace Velocity300400500600700
12x12Cfm216289361433505
Ak .722Pt.011.020.032.045.062
14x14Cfm300400500600700
Ak 1.000Pt.011.019.030.043.059
16x16Cfm397530662794927
Ak 1.324Pt.010.018.029.042.057
18x12Cfm325433541649758
Ak 1.082Pt.011.019.030.043.059
18x18Cfm4926568209841147
Ak 1.639Pt.010.018.027.040.055
20x10Cfm293391488586684
Ak .977Pt.011.019.030.043.059
20x12Cfm354472590707825
Ak 1.179Pt.011.019.030.042.057
20x14Cfm414552691829967
Ak 1.381Pt.010.0189.029.041.056
20x16Cfm4756337929501108
Ak 1.583Pt.010.018.029.040.056
20x20Cfm59679599411931391
Ak 1.988Pt.010.017.028.039.053
24x12Cfm4335777228661010
Ak 1.443Pt.010.018.029.041.056
24x14Cfm50767684510141184
Ak 1.691Pt.010.018.028.040.055
24x18Cfm656874109313111530
Ak 2.186Pt.010.017.027.039.052
24x20Cfm730973121614601703
Ak 2.433Pt.009.017.027.038.052
24x24Cfm8781171146417572049
Ak 2.928Pt.009.016.026.037.050
25x14Cfm51869186310361209
Ak 1.726Pt.010.018.029.040.055
25x16Cfm59479299011871385
Ak 1.979Pt.010.017.028.039.054
25x20Cfm745994124214911739
Ak 2.484Pt.009.017.027.038.052
25x25Cfm9351246155818702181
Ak 3.116Pt.009.016.026.036.050
30x10Cfm4405867338791026
Ak 1.465Pt.010.018.029.041.055
30x12Cfm53170788410611238
Ak 1.769Pt.010.018.028.040.054
30x14Cfm622829103612431450
Ak 2.072Pt.010.017.027.039.052
30x20Cfm8941193149117892087
Ak 2.981Pt.009.016.026.037.050
30x24Cfm10761435179421532511
Ak 3.588Pt.009.016.025.036.048
30x30Cfm13491799224926983148
Ak 4.497Pt.007.015.025.034.048

Note:

Submittals sheets are available as interactive pdf forms which can be completed electronically. To access this functionality, you must download the sheets and open in a pdf reach such as the Adobe Reader.
By default, these submittals will open in a new browser window. Browsers do not support interactive pdf fields.
