Floor, Toe Space, & Baseboard
F20
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec eget auctor velit, et suscipit erat. Donec dapibus purus id eros auctor, a scelerisque urna ornare. Pellentesque vel bibendum arcu, a hendrerit purus. Etiam vel arcu quis nibh blandit faucibus. Morbi id purus diam. Vestibulum eu congue nisi, id dictum ex.
Bar face- Smooth surface
- Multi-shutter damper
- Extremely rigid
- Available widths: 4”, 6”, 8”, 9”, 10”, 12”, 14”
- Golden Brown finish
- Steel construction
- Made in the U.S.A.
| Part # | Description | Ctn Qty | List Price Each |
|---|---|---|---|
| F20B0608 | 6" X 8" Brown | 10 | -- |
| F20B0610 | 6" X 10" Brown | 10 | -- |
| F20B0612 | 6" x 12" Brown | 10 | -- |
| F20B0614 | 6" x 14" Brown | 10 | -- |
| F20B0808 | 8" x 8" Brown | 10 | -- |
| F20B0810 | 8" x 10" Brown | 10 | -- |
| F20B0812 | 8" x 12" Brown | 10 | -- |
| F20B0814 | 8" x 14" Brown | 10 | -- |
| F20B0912 | 9" x 12" Brown | 10 | -- |
| F20B1012 | 10" x 12" Brown | 5 | -- |
| F20B1014 | 10" x 14" Brown | 5 | -- |
| F20B1212 | 12" x 12" Brown | 5 | -- |
| F20B1214 | 12" x 14" Brown | 5 | -- |
| Unit | Face Velocity | 300 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | |
|---|---|---|---|---|---|---|---|---|---|---|
| Size | Pressure Loss | .006 | .010 | .016 | .022 | .031 | .040 | .050 | .062 | |
| 4x8 | Cfm | 48 | 64 | 80 | 96 | 112 | 128 | 144 | 160 | |
| Ak .160 | Throw | 5 | 7 | 9 | 11 | 12 | 14 | 16 | 17 | |
| 4x10 | Cfm | 60 | 80 | 100 | 121 | 141 | 161 | 181 | 201 | |
| Ak .201 | Throw | 8 | 11 | 13 | 16 | 19 | 22 | 24 | 26 | |
| 4x12 | Cfm | 73 | 97 | 122 | 146 | 170 | 194 | 219 | 243 | |
| Ak .243 | Throw | 9 | 12 | 15 | 18 | 21 | 25 | 28 | 31 | |
| 6x6 | Cfm | 54 | 72 | 91 | 109 | 127 | 145 | 163 | 181 | |
| Ak .181 | Throw | 6 | 8 | 10 | 12 | 14 | 15 | 16 | 17 | |
| 6x8 | Cfm | 75 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | |
| Ak .250 | Throw | 9 | 12 | 15 | 18 | 21 | 25 | 28 | 31 | |
| 6x10 | Cfm | 91 | 125 | 157 | 188 | 219 | 250 | 282 | 313 | |
| Ak .313 | Throw | 10 | 14 | 17 | 21 | 24 | 27 | 31 | 34 | |
| 6x12 | Cfm | 110 | 147 | 184 | 221 | 258 | 294 | 331 | 368 | |
| Ak .368 | Throw | 12 | 15 | 19 | 23 | 26 | 30 | 34 | 38 | |
| 6x14 | Cfm | 129 | 172 | 216 | 259 | 302 | 345 | 388 | 431 | |
| Ak .431 | Throw | 13 | 16 | 20 | 24 | 28 | 32 | 36 | 41 | |
| 6x16 | Cfm | 148 | 197 | 247 | 296 | 345 | 394 | 444 | 493 | |
| Ak .493 | Throw | 11 | 16 | 21 | 25 | 30 | 35 | 39 | 44 | |
| 8x8 | Cfm | 96 | 128 | 160 | 192 | 224 | 256 | 288 | 320 | |
| Ak .320 | Throw | 10 | 14 | 17 | 21 | 24 | 27 | 31 | 34 | |
| 8x10 | Cfm | 127 | 170 | 212 | 254 | 297 | 339 | 382 | 424 | |
| Ak .424 | Throw | 12 | 15 | 18 | 24 | 28 | 32 | 37 | 41 | |
| 8x12 | Cfm | 148 | 197 | 247 | 296 | 345 | 394 | 444 | 493 | |
| Ak .493 | Throw | 12 | 17 | 21 | 26 | 32 | 37 | 43 | 48 | |
| 8x14 | Cfm | 171 | 228 | 285 | 341 | 398 | 455 | 512 | 569 | |
| Ak .569 | Throw | 14 | 20 | 24 | 29 | 34 | 39 | 44 | 50 | |
| 9x12 | Cfm | 176 | 235 | 294 | 352 | 411 | 470 | 528 | 587 | |
| Ak .587 | Throw | 14 | 20 | 24 | 29 | 34 | 39 | 44 | 50 | |
| 10x10 | Cfm | 149 | 199 | 249 | 299 | 349 | 398 | 448 | 498 | |
| Ak .498 | Throw | 12 | 17 | 21 | 26 | 32 | 37 | 43 | 48 | |
| 10x12 | Cfm | 183 | 244 | 306 | 367 | 428 | 489 | 550 | 611 | |
| Ak .611 | Throw | 14 | 18 | 24 | 30 | 35 | 41 | 46 | 51 | |
| 10x14 | Cfm | 219 | 292 | 365 | 438 | 510 | 583 | 656 | 729 | |
| Ak .729 | Throw | 14 | 21 | 28 | 34 | 40 | 46 | 51 | 56 | |
| 12x12 | Cfm | 221 | 294 | 368 | 442 | 515 | 589 | 662 | 736 | |
| Ak .736 | Throw | 14 | 21 | 28 | 34 | 40 | 46 | 51 | 56 | |
| 12x14 | Cfm | 247 | 329 | 411 | 493 | 575 | 658 | 740 | 822 | |
| Ak .822 | Throw | 18 | 24 | 30 | 37 | 43 | 50 | 56 | 62 | |
| Terminal Velocity of 50 fpm |
